SRW2024-K9-EU
Brand name: CISCO SRW2024-K9-EU
Model: SRW2024-K9-EU
Short Description: The Cisco SG300-28 switch is an affordable 28-port managed Gigabit (10/100/1000) switch, including two combination mini-GBIC ports, that delivers the performance required for high-bandwidth applications.
It offers the security and advanced network features needed to support business-class data, voice, security, and wireless solutions. With energy-saving technology, the switch optimizes power use to help protect the environment and reduce energy costs without compromising performance. It is easy to configure and manage with intuitive browser-based tools and is offered with a limited lifetime warranty, including next business day advance replacement and one year of technical support. The Cisco SG300-28 provides the ideal combination of affordability, performance, and capabilities in a switch designed specifically for small businesses.
Data transmission
Maximum data transfer rate 1 Gbit/s
Supported data transfer rates 10/100/1000 Mbit/s
Switching capacity 56 Gbit/s
10G support N
Networking
MAC address table 8000 entries
DHCP client Y
DHCP server Y
IP routing Y
Spanning tree protocol Y
IGMP snooping Y
Number of VLANs 256
Routing entries 32
Networking standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1Q/p, IEEE 802.1w, IEEE 802.1s, IEEE 802.1X, IEEE 802.3af, IEEE 802.3at
Networking features Ethernet, Fast Ethernet, Gigabit Ethernet
Management features
Switch type Managed
Switch layer L3
Quality of Service (QoS) support Y
Web-based management Y
Wireless LAN features
Wireless LAN (WLAN) connection N
Protocols
Management protocols SNMP 1/2c/3, RMON, HTTP/HTTPS, TFTP, DHCP, SSH, RADIUS, BOOTP, SNTP
Connectivity
Ports quantity 28
Copper ethernet cabling technology 10BASE-T/100BASE-TX/1000BASE-T
Gigabit Ethernet (copper) ports quantity 26
Ethernet LAN (RJ-45) ports quantity 28
SFP slots quantity 2
Memory
Internal memory 128 MB
Flash memory 16 MB
Security
Authentication method RADIUS, MD5
MAC address filtering Y
Access Control List (ACL) Y
SSH/SSL support Y
Weight & dimensions
Rack mounting 19"
Dimensions W x D x H 440 x 257 x 44.45 mm
Stackable N
Energy management
Power over Ethernet (PoE) Support N
Power consumption 30.1/30.3 W
Power supply type AC
Heat dissipation 103.4 BTU/h
System requirements
Minimum system requirements Mozilla Firefox 2.5, Microsoft Internet Explorer 6
Endurance
Mean time between failures (MTBF) 179141 h
Certificates
Certification UL (UL 60950), CSA (CSA 22.2), CE, FCC 15 (CFR 47) A
Environmental conditions
Operating relative humidity range 10 - 90 %
Operating temperature range (T-T) 0 - 40 °C
Storage temperature range (T-T) -20 - 70 °C
Non-operating relative humidity (non-condensing) 10 - 90 %
Technical details
Connectivity technology Wired
