HVJ30 1.14kv ͹ᷤ٭ҡ vacuum contactor 1000A 1250A


Թ :    HVJ30 1.14kv ͹ᷤ٭ҡ vacuum contactor 1000A 1250A
觫 (Order Code) :    TTN00-09428
(Model) :    1.14KV ͹ᷤ٭ҡ
(Brand) :    Jucro

Ҥһ :  0
ҤҾҧʵ͡ :  0
ʹԹѴ :  0
Save :   0%
Stock :

Clearance Product Fullsize

HVJ30 1.14kv vacuum contactor  vacuum contactor 1000A 1250A.

HVJ30-1.14 / 1000.1250 Series Vacuum AC contactor is applicable for AC 50HZ Power System Voltage 1.14KV of rated current and rated up to open and close the 1,000th A ~ 1250Ato Circuit, Start and Control AC Motor Frequently. It is composed Suitable for Magnetic. Various starter with Protective Devices (JDB Integrated Electronic Protector, JR9 Protection Device Type over current, resistance-capacitance absorbers). It is particularly Suitable for Explosion-Proof compose a starter and Large Magnetic Mineral Switchgear.

Type

Unit

HVJ30-1.14 / 1000

HVJ30-1.14 / 1250

Rated voltage

KV

1.14

1.14

Rated current

A

1000

1250

Making capacity

A

5000 (100 times)

Breaking capacity

A

4500 (10 times)

Limit breaking capacity

A

5000 (3 times)

Electrical life times (AC3)

times

600 000

Electrical life times (AC4)

times

6000

Mechanical life times

times

1000000

Rated operating frequency (AC3)

times / h

600

Rated operating frequency (AC4)

times / h

120

Short-time operating frequency (20s).

times / h

1000

Contacts separation

mm

2.8 ± 0.1

Over travel

mm

1.0 ± 0.1
