HVJ20 2KV ͹ᷤ٭ҡ VC vacuum contactor 630A 800A


Թ :    HVJ20 2KV ͹ᷤ٭ҡ VC vacuum contactor 630A 800A
觫 (Order Code) :    TTN00-09427
(Model) :    2KV ͹ᷤ٭ҡ
(Brand) :    Jucro

Ҥһ :  0
ҤҾҧʵ͡ :  0
ʹԹѴ :  0
Save :   0%
Stock :
Ṻ :   2KV ͹ᷤ٭ҡ

Clearance Product Fullsize

2KV vacuum contactors

HVJ20 Series Vacuum contactor has Higher rated current, smaller Size and Anti-Dusty advantages. It Can be used in AC50 ~ 60Hz, 2kV Power System, rated current to 800A, for long Distance-Making and Breaking Frequent Starting and Controlling of AC Motor.

Items

Unit

HVJ20-630

HVJ20-800

Main circuit rate voltage

(KV)

2

2

Main circuit rate current

(A)

630

800

Main circuit making ability

(A / 100 times)

6300

6300

Main circuit break-make ability

(A / 10 times)

5000

6000

Maximum breaking ability

(A / 3 times)

6300

6300

Electrical life AC3

(Times)

600 000

600 000

Electrical life AC4

(Times)

100 000

100 000

Mechanical life

(Times)

1000000

1000000

Rated operating frequency AC3

(Times / h)

300

300

Rated operating frequency AC4

(Times / h)

120

120

Short-time operating frequency

times / h (20S)

1200

1200

Clearance between open contacts

mm

3 ± 0.3

3 ± 0.3

Over travel

mm

≥1

≥1
