HVJ6 JCZ5 12kv �͹ᷤ�٭�ҡ�� vacuum contactor 200A 400A 630A

1. Introduction

JCZ5 12kv vacuum contactors  vacuum contactor.

Indoor High-Voltage Vacuum Series HVJ6-12 AC contactor has Two types: One is holding Type Mechanical, the Other is holding Electromagnetic Type. It is applicable for Three-phase AC 50HZ Voltage Power System of rated current up to 12KV and Below and rated. 630 A to open and close Circuit remotely and Control Electrical Equipment like High-Voltage Motor, Transformer and capacitive Load. It is especially Suitable for fields operated Frequently. The contactor uses the International fashionable up and down structure Arrangement and has the advantages of Small,. light, easy to maintain and form a complete set of circuit equipment.

2. Service condition

a) Ambient air temperature: -25 ? - + 40 ?.

b) Altitude not exceed 2000m

c) Humidity:

-Relative Humidity: daily mean not higher than 95 ?, monthly mean not higher than 90 ?;

-Aqueous Vapor pressure: daily mean not exceed 2.2 KP, monthly mean not exceed 1.8 KP.

Ambient air should not be obviously polluted by corrosive or flammable gas or vapor;

C) Free of Frequent severe vibration; When running, Angle of inclination between surface and horizontal Installation Plane should not Exceed 5 ?.

Main technical parameters
